Lichtbron
Lichtbron12x3W RGB LEDs
Luminous flux1'247lm
Lux1'172lx @3 m
Levensverwachting lichtbron > 50.000 h
Optiek
Lens diameter42mm
Kleuren
Manual colour mode manual adjustment of colour
Kleurmenging RGB / FC
Kleurenwiel virtual colour wheel with macros
Effecten
Macros several pre-build pixel macros with adjustable speed
Body
Behuizing sturdy die-cast aluminium body
Aansturing
Protocolen DMX512
DMX kanalen3 / 4 / 6 / 7 / 8 / 9 / 12 / 18 / 36 / 41channel
Master/Slave for synchronised operation of more units linked in a chain
Display LED display user interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 / 28
LED Control flicker free operation
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik50,5W
Output (at 230V)47 units on a single power line
Fysieke eigenschappen
Koeling passive cooling and fan-free
Bevestiging double hanging bracket suitable for safe hanging and for floor positioning
Signaal aansluiting XLR 3p IN/OUT connectors
Stroomaansluiting IEC IN/OUT connectors
IP waarde33
Logistieke eigenschappen
Hoogte
4.9 cm
Breedte
98.7 cm
Diepte
15.7 cm
Gewicht
2.8 kg
