Algemeen
Artikelnummer
23-00037
Merk
ProLights
Artikelnummer fabrikant
LUMIPAR12UQPRO5
Garantie
2 jaar
Lichtbron
Lichtbron12x8W RGBW LEDs
CCTW: 6.600K
Luminous flux3'035,7lm
Lux3'113lx @3 m full
Levensverwachting lichtbron > 50.000 h
Optiek
Lens diameter38mm
Extra optieken25° (inc) - 45° (op)
Kleuren
Manual colour mode manual adjustment of dimmer and strobe
Kleurmenging RGBW / FC
Kleurenwiel virtual colour wheel with macros
Behuizing
Kleur behuizing black
Materiaal sturdy die-cast aluminium body
Aansturing
Protocollen DMX512
DMX kanalen4 / 9channel
Master/Slave for synchronised operation of more units linked in a chain
Display LED display user interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
W-DMX optional, proprietary protocol compatible with WIFIBOX, WDBOX
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 28 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free operation
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik77W
Output (at 230V)17 units on a single power line
Fysieke eigenschappen
Koeling passive cooling and fan-free
Bevestiging double hanging bracket suitable for safe hanging and for floor positioning
Signaal aansluiting variants available
Stroomaansluiting variants available
IP waarde44
Logistieke eigenschappen
Gewicht verpakking
3.75 kg
