Lichtbron
Lichtbron16x12W RGBWAP LEDs
Luminous flux3'408lm
Lux(15°) 1'986lx @3 m full
Levensverwachting lichtbron > 50.000 h
Optiek
Lens diameter42mm
Extra optieken25° and 45° (optional)
Kleuren
Manual colour mode manual adjustment of colour
Kleurmenging RGBWAP / FC
Wit macro's3.200 K -10.000K
Kleurenwiel virtual colour wheel with macros
Effecten
Macros several pre-build pixel macros with adjustable speed
Behuizing
Kleur behuizing black
Materiaal sturdy aluminum profile
Aansturing
Protocollen DMX512
DMX kanalen3 / 6 / 8 / 12 / 96 / 101channel
Master/Slave for synchronised operation of more units linked in a chain
Display LCD display
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1-25 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free operation
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik164W
Output (at 230V)12 units on a single power line
Power factorpF 0,99 @120 V - pF 0,94 @230 V
Fysieke eigenschappen
Koeling passive cooling and fan-free
Bevestiging bracket for hanging and positioning
Signaal aansluiting XLR 3p + 5p IN/OUT connectors
Stroomaansluiting Neutrik powerCON IN/OUT connectors
IP waarde33
Logistieke eigenschappen
Gewicht verpakking
6.5 kg
