Algemeen
Artikelnummer
21-00606
Merk
ProLights
Artikelnummer fabrikant
MOSAICOXLPLUS
Garantie
2 jaar
Aansturing
Stand AloneStand Alone programmer and playback
Lichtbron
Lichtbron600W high-power white LED
CCTlinear CTO correction 3.000 K ~ 6.000 K
Luminous flux(6,8°) 17'404 lm - (52,1°) 23'570 lm @Full
Lux(6,8°) 59'962 lx - (52,1°) 1'454lx @5 m full
Levensverwachting lichtbron> 20.000 h
Optiek
Lens diameter135mm
Lens typehigh-quality glass lens optics
Focusmotorised
Kleuren
Kleurmenginglinear CMY
Kleurenwielopen + 6 interchangeable colour filters
Effecten
Roterende gobo's7 rotating gobos + open, interchangeable, indexing
Prisma4f with bi-directional rotation, indexing
Frostdual frost filter, soft-edge and heavy
Messen systeem4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete fr
Animatiewielanimation wheel with CW and CCW rotation
Iris5 ~ 100% motorised iris
Behuizing
Kleur behuizingRAL 9006
Materiaalsturdy die-cast aluminium body, scratch resistant paint C5M (as standard)
Aansturing
ProtocollenDMX512, RDM, CRMX
DMX kanalen28 / 30 / 35 / 44channel
Master/Slavefor synchronised operation of more units linked in a chain
Displayblack OLED touch display
Firmware upgradevia DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-20° C / +45° C (-4° F / +113° F) Ta
LED Controlflicker free operation
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 40.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik680W
Output (at 230V)4 units on a single power line
Power factor>0,96
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingbracket for hanging and positioning
Signaal aansluiting1,8 m moulded IP signal IN/OUT connectors
Stroomaansluiting1,8 m moulded IP power IN/OUT connectors
IP waardeIP66 for outdoor installations
Logistieke eigenschappen
Hoogte verpakking
40.5 cm
Breedte verpakking
72 cm
Diepte verpakking
47.5 cm
Gewicht verpakking
40.2 kg
