Lamp eigenschappen
KleursysteemKleurenwiel
AansturingCRMX, DMX, RDM
Vermogen300W
SerieMosaico
Aansturing
Stand AloneStand Alone programmer and playback
Lichtbron
Lichtbron300W high-power white LED
CCT8.000
Luminous flux(7°) 8'536 lm - (49°) 11'729 @Full
Lux(7°) 28'230 lx - (49°) 867lx @5 m full
Levensverwachting lichtbron> 30.000 hrs (L70B10 @Ta 25° C / 77° F)
Optiek
Lens diameter110mm
Lens typeHD anti-reflection lenses with achromatic coating
Focusmotorised
Kleuren
Kleurmengingcold white LED with colour wheel
Kleurenwielopen + 7 colour filters
Effecten
FX generatorshutter macros with adjustable speed
Roterende gobo'sopen + 7 rotating gobos + open, interchangeable, indexing
Prisma3ff with bi-directional rotation, indexing
Frostlinear 0 - 100% frost filter
Messen systeem4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete fr
Animatiewielmagnetic interchangeable animation wheel with CW and CCW rotation
Control Resolution16-bit dimmer
Behuizing
Kleur behuizingBeige, RAL 9006
MateriaalAluminium
Aansturing
ProtocollenDMX512, RDM, CRMX
DMX kanalen22 / 32 / 43channel
DisplayGraphic User Interface
Firmware upgradevia DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1~30 Hz, electronic
Bedrijfstemperatuur-20° C / +45° C (-4° F / +113° F) Ta
LED Controlflicker free frequency with adjustable PWM
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Voedingstype230V AC
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik440W
Output (at 230V)6 units on a single power line
Power factor> 0,98
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingbracket for hanging and positioning
Signaal aansluiting1,8 m moulded IP signal IN/OUT connectors
Stroomaansluiting1,8 m moulded IP power IN/OUT connectors
IP waarde66 for outdoor installations, IP66
Montage mogelijkhedenOpbouw
Logistieke eigenschappen
Hoogte verpakking
36.5 cm
Breedte verpakking
62 cm
Diepte verpakking
41.5 cm
Gewicht verpakking
23.8 kg
