Lamp eigenschappen
KleursysteemKleurenwiel
AansturingCRMX, DMX, RDM
Vermogen250W
SerieMosaico
Aansturing
Stand AloneStand Alone programmer and playback
Lichtbron
Lichtbron250W high-power white LED
CCT8.500
Luminous flux(12.9°) 10'740 lm - (46.5°) 11'667 @Full
Lux(12.9°) 10'512 lx - (46.5°) 1'409lx @5 m full
Levensverwachting lichtbron> 30.000 hrs (L70B10 @Ta 25° C / 77° F)
Optiek
Lens diameter109mm
Lens typehigh-quality glass lens optics
Focusmotorised
Kleuren
Kleurenwiel14 colour filters on two colour wheels
Effecten
Roterende gobo's7 rotating gobos + open, interchangeable, indexing
Prisma3f with bi-directional rotation, indexing
Frostlinear 0 - 100% frost filter
Animatiewielanimation wheel with CW and CCW rotation
Iris5 - 100% motorised iris
Behuizing
Kleur behuizingGrijs
MateriaalAluminium
Aansturing
ProtocollenDMX512, RDM, CRMX
DMX kanalen12 / 14 / 16 / 19channel
Displayblack OLED touch display
Firmware upgradevia DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1~30 Hz, electronic
Bedrijfstemperatuur-20° C / +45° C (-4° F / +113° F) Ta
Elektrische eigenschappen
Voedingstype230V AC
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik320W
Output (at 230V)6 units on a single power line
Power factor>0,95
Fysieke eigenschappen
Koelingactive, with IP low noise fan
Bevestigingbracket for hanging and positioning
Signaal aansluiting1,8 m moulded IP signal IN/OUT connectors
IP waardeIP66
Montage mogelijkhedenOpbouw
Logistieke eigenschappen
Hoogte verpakking
35.5 cm
Breedte verpakking
62 cm
Diepte verpakking
42.5 cm
Gewicht verpakking
23.6 kg
