Lamp eigenschappen
KleursysteemMono-color
AansturingDMX, RDM, W-DMX G3
Vermogen70W
Zoom14.7° - 45° motorised linear zoom
SerieMosaico
Lichtbron
Lichtbron70W White LED
CCT7.000K
Luminous flux(14.7°) 2'595 lm - (45°) 2'628lm
Lux(14.7°) 1'927 lx - (45°) 294lx @5 m full
Levensverwachting lichtbron 30.000 hrs (L70 @25° C / 77° F)
Optiek
Lens diameter63mm
Lens type high-quality glass lens optics
Focus motorised
Kleuren
Kleurenwiel7 colour filters
Effecten
Roterende gobo's7 rotating gobos + open, indexing
Gobo maatgobo Ø 15,8 mm - img Ø 12,7 mm - 1,10 mm
Behuizing
Kleur behuizing RAL 9006
MateriaalAluminium
Aansturing
Protocollen DMX512, RDM, W-DMX, Stand Alone programmer and playback
DMX kanalen8 / 14channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
W-DMX included, wireless solution receiver
RDM RDM ready for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 ~ 21 Hz, electronic
Bedrijfstemperatuur -20° C / +45° C (-4° F / +113° F)
LED Control flicker free frequency with adjustable PWM
Display accu self-charging battery backup
Elektrische eigenschappen
Voedingstype230V AC
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik80W
Power factor>0,92
Fysieke eigenschappen
Koeling active, with IP low noise fan
Bevestiging bracket for hanging and positioning
Signaal aansluiting moulded IP signal IN/OUT connectors
Stroomaansluiting moulded IP power IN/OUT connectors
IP waarde66 for outdoor installations, IP66
Montage mogelijkhedenOpbouw
Logistieke eigenschappen
Hoogte verpakking
24.7 cm
Breedte verpakking
24.5 cm
Diepte verpakking
25.8 cm
