Algemeen
Artikelnummer
21-00620
Merk
ProLights
Artikelnummer fabrikant
ECLDISPLAYXBFCB
Garantie
2 jaar
Aansturing
Stand Alone1 push encoder
Lichtbron
Lichtbron40W RGB + lime LEDs
CCTCCT control through dedicated DMX channel
Luminous flux(profile 36 HD) 644 lm; (profile 2040 HD - min) 584 lm - (profile 2040 HD - max) 571 @Full
Lux(profile 36 HD) 121 lx; (profile 2040 HD - min) 372 lx - (profile 2040 HD - max) 107lx @5
Levensverwachting lichtbron> 50.000 hrs (L70B10 @Ta 25° C / 77° F)
Kleuren
KleurmengingRGB + lime / full colour
Kleurenwielvirtual colour wheel with macros
Effecten
Control Resolution16-bit dimmer, colours
Behuizing
Kleur behuizingRAL 9004 or RAL 9010
Materiaalaluminium die-casting
Aansturing
ProtocollenDMX512, RDM, CRMX (optional)
DMX kanalen5 / 6 / 15channel
Displayuser interface through DATAMASTER external coder (not included)
Firmware upgradevia DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
LED Controlflicker free operation
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik38W
Output (at 230V)35 units on a single power line
Power factor> 0,94
Fysieke eigenschappen
Koelingnatural convection cooling enabled by a fanless design and a chassis engineered for passiv
Bevestigingtrack / hanging / ceiling installation
Stroomaansluitingscrew terminal blocks
IP waardeIP20
