Algemeen
Artikelnummer
21-00589-0001
Merk
ProLights
Artikelnummer fabrikant
GALLERYWASHDATFCB
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGB+WW - Full Color
AansturingDMX, RDM
Vermogen60W
SerieEclGallery
Lichtbron
Lichtbron60W RGB + Warm White LED
CCTCCT control through dedicated DMX channel
Luminous flux2'932 lm @3.200 K; 2'468 lm @5.600 K; 2'582 lm @Full
Lux36lx @5 m 3.200 K; 30lx @5 m 5.600 K; 32lx @5 m full
Levensverwachting lichtbron> 50.000 hrs (L70B10 @Ta 25° C / 77° F)
CRI95,3 @3.200 K; 92,8 @5.600 K
R993,4 @3.200 K; 97,3 @5.600 K
TLCI86 @3.200 K; 90 @5.600 K
TM30 Rf92,9 @3.200 K; 90,6 @5.600 K
TM30 Rg105,2 @3.200 K; 106,2 @5.600 K
Optiek
Extra optiekenSmooth filter on-board - see available accessories
Kleuren
KleurmengingRGB + Warm White
Wit macro's2'800K - 10'000K
Effecten
Control Resolution16-bit dimmer, colours
Behuizing
Materiaalaluminium die-casting
Aansturing
ProtocollenLocal Knob, DMX, RDM, CRMX (optional)
DMX kanalen5 / 6 / 10 / 15channel
Displayuser interface through DATAMASTER external coder (not included)
Firmware upgradevia DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45° Ta
LED Controlflicker free operation
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Voedingstype230V AC
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik51W
Power factor> 0,9
Fysieke eigenschappen
Koelingnatural convection cooling enabled by a fanless design and a chassis engineered for passiv
Bevestigingtrack / hanging / ceiling installation
IP waardeIP20
Montage mogelijkhedenLichtrail, Opbouw, Plafond, Wand
Logistieke eigenschappen
Gewicht verpakking
5.25 kg
