Algemeen
Artikelnummer
21-00340
Merk
ProLights
Artikelnummer fabrikant
ECLDISPLAYUNFCB
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGBWW - Full Color
AansturingDALI, DMX, RDM
Vermogen40W
Zoom(wash lens - optional) 15° ~ 30° or 25° ~ 50° - (profile lens - optional) 20° ~ 40°
SerieEclDisplay
Lichtbron
Lichtbron40W RGB + Warm White LED
CCT CCT control through dedicated DMX channel
Luminous flux(profile - 20°) 366 lm - (profile - 40°) 325 lm; (wash 2550 - min) 308 lm - (wash 2550 - max) 407 lm; (wash 1530 - min) 309 lm - (wash 1530 - max) 343lm @full
Lux(profile - 20°) 194 lx - (profile - 40°) 42lx; (wash 2550 - min) 49 lx - (wash 2550 - max) 20 lx; (wash 1530 - min) 119 lx - (wash 1530 - max) 58lx @5 m full
Levensverwachting lichtbron > 50.000 hrs (L70B10 @Ta 25° C / 77° F)
Kleuren
Kleurmenging RGB + Warm White
Kleurenwiel virtual colour wheel with macros
Effecten
Control Resolution 16-bit dimmer, colours
Behuizing
Kleur behuizing RAL 9004 or RAL 9010
MateriaalAluminium
Aansturing
ProtocollenLocal Knob, DMX, DALI Type8, RDM, cut phase dimming
DMX kanalen5 / 6 / 15channel
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
LED Control flicker free operation
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Voedingstype230V AC
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik35W
Power factor> 0,94
Fysieke eigenschappen
Koeling passive cooling and fan-free
Bevestigingtrack / hanging / ceiling installation
Stroomaansluitingscrew terminal blocks
IP waardeIP20
Montage mogelijkhedenOpbouw, Plafond
