Algemeen
Artikelnummer
21-00332
Merk
ProLights
Artikelnummer fabrikant
ECLDISPLAYUN27KB
Garantie
2 jaar
Lamp eigenschappen
KleursysteemMono-color
AansturingDALI, DMX, RDM
Vermogen25W
Zoom(wash lens - optional) 15° ~ 30° or 25° ~ 50° - (profile lens - optional) 20° ~ 40°
SerieEclDisplay
Lichtbron
Lichtbron25W White COB LED
Luminous flux(4.000 K - 17°) 1'576 lm - (4.000 K - 36°) 1'810 lm - (5.600 K - 17°) 1'631 lm - (5.600 K - 36°) 1'869 lm @ full
Lux(4.000 K - 17°) 923 lx - (4.000 K - 36°) 245 lx - (5.600 K - 17°) 964 lx - (5.600 K - 36°) 256lx @5 m full
Levensverwachting lichtbron > 50.000 hrs (L70B10 @Ta 25° C / 77° F)
CRI90.5 @2.800 K; 90 @3.000 K; 92.9 @4.000 K; 90.5 @5.600 K
TLCI87 @2.800 K; 88 @3.000 K; 94 @4.000 K; 93 @5.600 K
TM30 Rf> 89 @2.800 K and 3.000 K; > 91 @4.000 K; > 88 @5.600 K
TM30 Rg 99 @4.000 K
Effecten
Control Resolution 16-bit dimmer
Behuizing
Kleur behuizing RAL 9004 or RAL 9010
MateriaalAluminium
Aansturing
ProtocollenLocal Knob, DMX, DALI Type6, RDM, cut phase dimming
DMX kanalen1 / 2 / 3 / 4channel
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
LED Control flicker free operation
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Voedingstype230V AC
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik33W
Power factor> 0,94
Fysieke eigenschappen
Koeling passive cooling and fan-free
Bevestigingtrack / hanging / ceiling installation
Stroomaansluitingscrew terminal blocks
IP waardeIP20
Montage mogelijkhedenInbouw, Opbouw
