Algemeen
Artikelnummer
21-00633
Merk
ProLights
Artikelnummer fabrikant
ECLFRFWXSVWBK
Garantie
2 jaar
Lamp eigenschappen
KleursysteemCC/CW - Tunable White
Vermogen120W
Aansturing
Stand Alone1 push encoder
Lichtbron
CCTCCT control range from 2.800K to 6.500K
Luminous flux(9,8°) 3.175 lm - (55,8°) 5'897 lm @Full
Lux(9,8°) 4'233 lx - (55,8°) 440lx @5 m full
Levensverwachting lichtbron> 50.000 hrs (L70B10 @Ta 25° C / 77° F)
CRI95,2 @3.200K; 93,8 @5.600K
R995,1 @3.200K; 98,7 @5.600K
TLCI92 @3.200K; 97 @5.600K
TM30 Rf91,8 @3.200K; 92,3 @5.600K
TM30 Rg107 @3.200K; 104,8 @5.600K
Optiek
Lens diameter5'' / 130mm
Lens typePMMA lens
Min. Zoombereik10
Max. Zoombereik56
BedieningHandmatig
Kleuren
Kleurmengingtunable white
Behuizing
Kleur behuizingZwart
Aansturing
DMX kanalenFrom 1 to 14ch
Master/Slavefor synchronised operation of more units linked in a chain
Display2.4'' Color display
Firmware upgradevia DMX with UPBOXPRO (USB-DMX interface not included)
RDMfor remote addressing and parameter configuration
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
BedrijfstemperatuurTa -10 to +45 °C (+14 to +113 °F)
LED Controlflicker free frequency with adjustable PWM
Selecteerbare PWM frequentie1282 to 40000 Hz (selectable steps)
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik130W
Output (at 230V)20 units on a single power line
Power factor> 0,94
DC spanning48V
Fysieke eigenschappen
Koelingforced-air with low-noise fan
StroomaansluitingPowerCon TRUE1
IP waardeIP20
Overige eigenschappen
Lichtbron120W Variable White LED
Singlecolor LED
