Algemeen
Artikelnummer
21-00594
Merk
ProLights
Artikelnummer fabrikant
ECLFRCTPXLIPBK
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGBCMA - Full Color
AansturingCRMX, DMX, RDM
Vermogen1200W
Aansturing
Stand Alone 4 pushable RGB backlit encoder
Lichtbron
R998 @3.200K; 97 @5.600K
TLCI95 @3.200K; 98 @5.600K
TM30 Rf>93 @3.200K; >93 @5.600K
Optiek
Lens diameter12'' / 300mm
Lens type Fresnel glass lens with AR coating
Kleuren
Kleurmenging6 colour LEDs source
Behuizing
Kleur behuizing RAL 9004
MateriaalMagnesium
Aansturing
Protocollen DMX512, RDM, CRMX
Master/Slave for synchronised operation of more units linked in a chain
Display 2.8'' Color display
Firmware upgrade via DMX with UPBOXPRO (USB-DMX interface not included)
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves6 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
LED Control flicker free frequency with adjustable PWM
Selecteerbare PWM frequentie 1282 ~ 40.000 Hz
Elektrische eigenschappen
Voedingstype230V AC
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik1260W
Power factor> 0,97
DC spanning48V (WEIPU SY25 4P connector)
Fysieke eigenschappen
Koeling combination of heat pipe cooling system and low noise fan
Signaal aansluitingIP65 Seetronic XLR 5p IN/OUT connectors
Stroomaansluiting Seetronic powerCON TRUE IP65 IN
DC Connector 48V WEIPU SY25 4P connector
IP waarde65 for temporary outdoor use (*)
