Algemeen
Artikelnummer
21-00495
Merk
ProLights
Artikelnummer fabrikant
ECLFRCTPMIPBK
Garantie
2 jaar
Aansturing
Stand Alone 4 pushable RGB backlit encoder
Lichtbron
Lichtbron350W 6 colour LEDs source
CCT Linear CCT adjustment from 1.800 K-20.000K
Luminous flux(9,4°) 3'867 lm - (80,8°) 9'827lm @4.000 K
Lux(9,4°) 5'706 lx - (80,8°) 451lx @5m @4.000 K
Levensverwachting lichtbron > 50.000 h
CRI97 @3.200K; 96,8 @5.600 K
R991,7 @3.200K; 96,9 @5.600 K
TLCI88 @3200K; 94 @5.600 K
TM30 Rf> 94 @3.200K; > 94 @5.600 K
TM30 Rg > 50.000 h
Optiek
Lens diameter8'' / 200mm
Lens type Fresnel glass lens with AR coating
Zoom9,4° - 80,8° manual
Extra optieken PC lens available as accessory
Kleuren
Kleurmenging6 colour LEDs source
Body
Kleur behuizing RAL 9004
Behuizing weatherproof IP65 construction with die-cast magnesium alloy
Aansturing
Protocolen DMX512, RDM, CRMX
Master/Slave for synchronised operation of more units linked in a chain
Display 2.8'' Color display
Firmware upgrade yes, via USB - DMX interface (UPBOXPRO) not included
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -20° ~ +45°
LED Control flicker free frequency with adjustable PWM
Selecteerbare PWM frequentie 600 ~ 40.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik350W
Output (at 230V)8 units on a single power line
Power factor> 0,94
DC spanning48V
Fysieke eigenschappen
Koeling combination of heat pipe cooling system and low noise fan
Signaal aansluitingIP65 Seetronic XLR 5p IN/OUT connectors
Stroomaansluiting Seetronic powerCON TRUE IP65 IN/OUT
DC Connector XLR 3p for 48V
IP waarde65 for temporary outdoor use (*)
