Lamp eigenschappen
KleursysteemRGBCMA - Full Color
Vermogen200W, 200W
Zoom9,7° - 73,5° manual
Aansturing
Stand Alone 4 pushable RGB backlit encoder
Lichtbron
Lichtbron200W 6 colour LEDs source
CCT Linear CCT adjustment from 1.800 K-20.000K
Luminous flux(9,7°) 1'922 lm - (73,5°) 4'795lm @4.000 K
Lux(9,7°) 2'270 lx - (73,5°) 286lx @5m @4.000 K
Levensverwachting lichtbron > 50.000 h
CRI96,6 @3.200K; 97 @5.600 K
R987 @3200K; 96 @5.600 K
TLCI87 @3200K; 94 @5.600 K
TM30 Rf> 94 @3.200K; > 94 @5.600 K
TM30 Rg Source life expectancy: > 50.000 h
Optiek
Lens diameter6'' / 150mm
Lens type Fresnel glass lens with AR coating
Extra optieken PC lens available as accessory
Min. Zoombereik10, 10, 10
Max. Zoombereik73, 73, 73
BedieningHandmatig, Pole operated
Kleuren
Kleurmenging6 colour LEDs source
Behuizing
Kleur behuizingZwart
Materiaal Die-cast magnesium alloy
Aansturing
Protocollen DMX512, RDM, CRMX
Master/Slave for synchronised operation of more units linked in a chain
Display 2.4'' Color display
Firmware upgrade yes, via USB - DMX interface (UPBOXPRO) not included
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free frequency with adjustable PWM
Selecteerbare PWM frequentie 600 ~ 40.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik200W
Output (at 230V)11 units on a single power line
Power factor> 0,94
DC spanning48V
Fysieke eigenschappen
Koeling combination of heat pipe cooling system and low noise fan
Signaal aansluiting Amphenol XLR 5p IN/OUT connectors
StroomaansluitingPowerCON TRUE1
DC Connector XLR 3p for 48V
IP waardeIP20
