Lamp eigenschappen
KleursysteemRGBCMA - Full Color
Vermogen600W
Zoom10° - 77° manual
Aansturing
Stand Alone4 pushable RGB backlit encoder
Lichtbron
Lichtbron600W 6 colour LEDs source
CCTLinear CCT adjustment from 1.800 K-20.000K
Luminous flux(10°) 5'859 lm - (77°) 13'814lm @4.000 K
Lux(10°) 6'085 lx - (77°) 732lx @5m @4.000 K
Levensverwachting lichtbron> 50.000 h
CRI97,6 @3.200K; 97,5 @5.600 K
R984,9 @3200K; 97,8 @5.600 K
TLCI88 @3200K; 94 @5.600 K
TM30 Rf> 94 @3.200K; > 94 @5.600 K
TM30 RgSource life expectancy: > 50.000 h
Optiek
Lens diameter10'' / 250mm
Lens typeFresnel glass lens with AR coating
Extra optiekenPC lens available as accessory
Min. Zoombereik10
Max. Zoombereik77
BedieningHandmatig, Pole operated
Kleuren
Kleurmenging6 colour LEDs source
Behuizing
Kleur behuizingRAL 9004, Zwart
MateriaalDie-cast magnesium alloy
Aansturing
ProtocollenDMX512, RDM, CRMX
Master/Slavefor synchronised operation of more units linked in a chain
Display2.8'' Color display
Firmware upgradeyes, via USB - DMX interface (UPBOXPRO) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free frequency with adjustable PWM
Selecteerbare PWM frequentie600 ~ 40.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik600W
Output (at 230V)4 units on a single power line
Power factor> 0,94
DC spanning48V
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN/OUT connectors, PowerCON TRUE1
DC ConnectorXLR 3p for 48V
IP waarde20, IP20
Logistieke eigenschappen
Hoogte verpakking
49.5 cm
Breedte verpakking
66.5 cm
Diepte verpakking
50 cm
Gewicht verpakking
23.9 kg
