Algemeen
Artikelnummer
21-00393
Merk
ProLights
Artikelnummer fabrikant
ECLFRESNELJVWBK
Garantie
2 jaar
Lamp eigenschappen
KleursysteemCC/CW - Tunable White
Vermogen150W
Zoom15,5° - 83° manual
Aansturing
Stand Alone3 rotatory knobs
Lichtbron
Lichtbron150W Variable White LED
CCTCCT control through dedicated DMX channel
Luminous flux(15,5°) 2'270 lm - (83°) 4'558lm @full
Lux(15,5°) 1'196 lx - (83°) 201lx @5 m full
Levensverwachting lichtbron> 50.000 h
CRI94 @WW; 95 @CW; 94 @full
R989 @WW; 88 @CW; 78 @full
TLCI98 @WW; 98 @CW; 98 @full
TM30 Rf>94 @WW; >93 @CW; >94 @full
Optiek
Lens diameter6'' - 150mm
Lens typefresnel zoom lens
Min. Zoombereik15
Max. Zoombereik83
BedieningHandmatig
Kleuren
Kleurmengingtunable white
Wit macro's2.700 K - 5.600K
Kleurenwielbuilt-in white presets
Effecten
Control Resolution16-bit dimmer
Behuizing
Pan angle(for pole operated version) 360° with manual regulation
Tilt angle(for pole operated version) 340° with manual regulation
Kleur behuizingRAL 9004 or RAL 9003, Zwart
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM
DMX kanalen1 / 2 / 4 / 5 / 11channel
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-20° ~ +45°
LED Controlflicker free frequency with adjustable PWM
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik125W
Output (at 230V)23 units on a single power line
Power factor> 0,95
Batterij29,6V 4400 mAh external battery (optional ECLFRSJBP4)
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingbracket for hanging and positioning
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN/OUT connectors, PowerCON True1
Oplaad connectieconnection for external battery throught XLR 4p
IP waarde20, IP20
Logistieke eigenschappen
Hoogte verpakking
36.5 cm
Breedte verpakking
41.5 cm
Diepte verpakking
30.5 cm
Gewicht verpakking
8.4 kg
