Algemeen
Artikelnummer
21-00397
Merk
ProLights
Artikelnummer fabrikant
ECLFR2KVWPOBK
Garantie
2 jaar
Lamp eigenschappen
KleursysteemCC/CW - Tunable White
Vermogen500W
Zoom15° - 79,5° manual
Aansturing
Stand Alone3 rotatory knobs
Lichtbron
Lichtbron500W Variable White LED
CCTCCT control through dedicated DMX channel
Luminous flux(15°) 12'196 lm - (79,5°) 19'711lm @full
Lux(15°) 6'782 lx - (79,5°) 1'118lx @5 m full
Levensverwachting lichtbron> 50.000 h
CRI94 @WW; 96 @CW; 92 @full
R990 @WW; 88 @CW; 73 @full
TLCI97 @WW; 99 @CW; 98 @full
TM30 Rf>94 @WW; >94 @CW; >93 @full
Optiek
Lens diameter9,84" - 250mm
Lens typefresnel zoom lens
Min. Zoombereik15
Max. Zoombereik80
BedieningPole operated
Kleuren
Kleurmengingtunable white
Wit macro's2.700 K - 5.600K
Kleurenwielbuilt-in white presets
Effecten
Control Resolution16-bit dimmer
Behuizing
Pan angle(for pole operated version) 360° with manual regulation
Tilt angle(for pole operated version) 180° with manual regulation
Kleur behuizingRAL 9004 or RAL 9003, Zwart
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM
DMX kanalen1 / 2 / 4 / 5 / 11channel
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-20° ~ +45°
LED Controlflicker free frequency with adjustable PWM
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik450W
Output (at 230V)5 units on a single power line
Power factor> 0,95
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingbracket for hanging and positioning
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN/OUT connectors, PowerCON TRUE1
IP waarde20, IP20
Logistieke eigenschappen
Hoogte verpakking
53 cm
Breedte verpakking
75.5 cm
Diepte verpakking
46.5 cm
Gewicht verpakking
21 kg
