Algemeen
Artikelnummer
21-00311
Merk
ProLights
Artikelnummer fabrikant
MINIECLFRVWBK
Garantie
2 jaar
Aansturing
Stand Alone3 rotatory knobs
Lichtbron
Lichtbron60W Variable White LED
CCT CCT control through dedicated DMX channel
Luminous flux(20°) 1'062 lm - (62°) 2'394lm @full
Lux(20°) 845 lx - (62°) 280lx @3 m
Levensverwachting lichtbron > 50.000 h
CRI97 @WW; 95 @CW; 95 @full
R990 @WW; 86 @CW; 86 @full
TLCI97 @WW; 98 @CW; 98 @full
TM30 Rf> 95 @WW; >92 @CW; > 93 @full
Optiek
Lens diameter3,93'' - 100mm
Lens typefresnel zoom lens
Zoom20° - 62° half peak angle
Kleuren
Manual colour mode manual adjustment of intensity and CT from knob
Kleurmenging tunable white
Wit macro's2.700 K - 5.600K
Kleurenwiel built-in white presets
Effecten
Control Resolution 16bit dimmer, colours
Body
Kleur behuizing RAL 9004 or RAL 9003
Behuizing sturdy die-cast aluminium body
Aansturing
Protocolen DMX512, RDM
DMX kanalen1 / 2 / 4 / 5 / 11channel
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
RDM RDM ready for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -20° ~ +45°
LED Control flicker free frequency with adjustable PWM
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik55W
Power factor> 0,95
Fysieke eigenschappen
Koeling passive cooling and fan-free
Bevestiging bracket for hanging and positioning
Signaal aansluiting DMX 5p IN/OUT
Stroomaansluiting 16 A Schuko plug
IP waarde20
