Algemeen
Artikelnummer
21-00306
Merk
ProLights
Artikelnummer fabrikant
ECLFRESNELJDYWH
Garantie
2 jaar
Lamp eigenschappen
KleursysteemMono-color
Vermogen70W
Zoom16° - 57° half peak angle
Lichtbron
Lichtbron70W high-power white LED
CCT(TU) 3.000 K - (DY) 5.600K
Luminous flux(DY) (16°) 3'656 lm ; (57°) 5'911 lm @ full
LuxDY (16°) 1'624 lx - (57°) 254lx @5 m full
Levensverwachting lichtbron> 50.000 h
CRI(TU) >97; (DY) >90
R9(TU) >95; (DY) >53
TLCI(TU) >97; (DY) >92
TM30 Rf(TU) >94; (DY) >88
TM30 Rg(TU) 97
Optiek
Lens diameter6'' - 150mm
Lens typefresnel zoom lens
Min. Zoombereik16
Max. Zoombereik57
BedieningHandmatig
Kleuren
Manual colour modemanual adjust of dimmer throught menu and knob
Behuizing
Pan angle(pole operated version) 360° with manual regulation
Tilt angle(pole operated version) 340° with manual regulation
Kleur behuizingWit, black, white finishing available
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM, rotatory knob
DMX kanalen1 / 2 - 1 / 2 - 2 / 3 / 5channel
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
RDMRDM ready for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter0 ~ 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free frequency with adjustable PWM
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik90W
Output (at 230V)23 units on a single power line
Power factor>0,95
Batterij29,6V 4400 mAh external battery (optional ECLFRSJBP4)
Fysieke eigenschappen
Koelingactive, silent operation
Bevestigingbracket for hanging and positioning
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN/OUT connectors, PowerCON TRUE1
IP waarde20, IP20
Oplaad connectieconnection for external battery throught XLR 4p
Logistieke eigenschappen
Hoogte verpakking
30 cm
Breedte verpakking
41 cm
Diepte verpakking
36 cm
Gewicht verpakking
8.8 kg
