Lichtbron
Lichtbron70W high-power white LED
CCT(TU) 3.000 K - (DY) 5.600K
Luminous flux(DY) (16°) 3'656 lm ; (57°) 5'911 lm @ full
LuxDY (16°) 1'624 lx - (57°) 254lx @5 m full
Levensverwachting lichtbron > 50.000 h
CRI(TU) >97; (DY) >90
R9(TU) >95; (DY) >53
TLCI(TU) >97; (DY) >92
TM30 Rf(TU) >94; (DY) >88
TM30 Rg(TU) 97
Optiek
Lens diameter6'' - 150mm
Lens typefresnel zoom lens
Zoom16° - 57° half peak angle
Kleuren
Manual colour mode manual adjust of dimmer throught menu and knob
Body
Pan angle360° with manual regulation
Tilt angle340° with manual regulation
Kleur behuizing black
Behuizing sturdy die-cast aluminium body
Aansturing
Protocolen DMX512, RDM, rotatory knob
DMX kanalen1 / 2 - 1 / 2 - 2 / 3 / 5channel
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
RDM RDM ready for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter0 ~ 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free frequency with adjustable PWM
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik90W
Output (at 230V)23 units on a single power line
Power factor>0,95
Batterij29,6V 4400 mAh external battery (optional ECLFRSJBP4)
Fysieke eigenschappen
Koeling active, silent operation
Bevestiging bracket for hanging and positioning
Signaal aansluiting Amphenol XLR 5p IN/OUT connectors
Stroomaansluiting Neutrik powerCON TRUE1 IN/OUT connectors
IP waarde20
Oplaad connectieconnection for external battery throught XLR 4p
