Lamp eigenschappen
KleursysteemROGRBBL - Full Color
Vermogen130W
Zoom15,5° - 55° half peak angle
Lichtbron
Lichtbron130W 6 colour custom LEDs source (red, orange, cyan, royal blue, green, lime)
CCTCCT control, + / - green correction, tungsten emulation
Luminous flux(15,5°) 1'610 lm - (55°) 2'952lm @full
Lux(15,5°) 709 lx - (55°) 145lx @5 m full
Levensverwachting lichtbron> 50.000 h
CRI91 @ 3200K; 92 @ 5600K
R991 @ 3200K; 92 @ 5600K
TLCI86 @ 5600K
TM30 Rf88 @ 3200K; 86 @ 5600K
TM30 Rg106 @ 3200K; 104 @ 5600K
Optiek
Lens diameter6'' - 150mm
Lens typefresnel zoom lens
Min. Zoombereik15
Max. Zoombereik55
BedieningPole operated
Kleuren
Manual colour modemanual adjustment of intensity, CT, colour correction from knob
Kleurmengingtunable white + colour
Wit macro's2.800 K - 10.000K
Kleurenwielvirtual colour wheel with macros
Effecten
Macrosseveral pre-build macros with adjustable speed
Behuizing
Pan angle360° with manual regulation
Tilt angle340° with manual regulation
Kleur behuizingZwart, black
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM, rotatory knob
DMX kanalen1 / 2 / 5 - 1 / 5 - 2 / 7 / 9 / 12 / 13 / 16 / 19 / 21channel
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
RDMRDM ready for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
LED Controlflicker free frequency with adjustable PWM
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik100W
Output (at 230V)23 units on a single power line
Power factor>0,95
Batterij29,6V 4400 mAh external battery (optional ECLFRSJBP4)
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingbracket for hanging and positioning
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN/OUT connectors, PowerCON TRUE1
IP waarde20, IP20
Oplaad connectieconnection for external battery throught XLR 4p
Logistieke eigenschappen
Hoogte verpakking
38.5 cm
Breedte verpakking
58.5 cm
Diepte verpakking
35 cm
Gewicht verpakking
8.5 kg
