Lichtbron
Lichtbron40W LEDs
CCT(TU) 3.050 K - (DY) 5.000K
Luminous flux(DY) (20°) 1'168 lm (64°) 2'851 lm @full
Lux(DY) (20°) 321 lx - (64°) 113lx @5 m full
Levensverwachting lichtbron > 50.000 h
CRI(TU) >92 - (DY) >81
TLCI(TU) >93; (DY) >67
TM30 Rf(TU) >90; (DY) >80
TM30 Rg(TU) >99; (DY) >95
Optiek
Lens diameter3,93'' - 100mm
Lens typeFresnel zoom lens
Zoom20° - 64° half peak angle
Kleuren
Manual colour mode manual adjust of dimmer throught menu and knob
Effecten
Macros several pre-build macros with adjustable speed
Body
Kleur behuizing black
Behuizing aluminium die-casting
Aansturing
Protocolen DMX512, RDM, rotatory knob
DMX kanalen1 / 2-1 / 2-2 / 3 / 5channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
RDM RDM ready for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100%, manual knob dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 28 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free frequency with adjustable PWM
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik35W
Power factor>0,55
Fysieke eigenschappen
Koeling passive cooling and fan-free
Bevestiging bracket for hanging and positioning
Signaal aansluiting DMX 5p IN/OUT
Stroomaansluiting 16 A Schuko plug
IP waarde20
Logistieke eigenschappen
Hoogte
19.1 cm
Breedte
20.3 cm
Diepte
27.9 cm
