Lamp eigenschappen
KleursysteemRGBL - Full Color
Vermogen70W
Zoom24° - 82° half peak angle
Lichtbron
Lichtbron70W RGB + lime LEDs
CCTCCT control through dedicated DMX channel and amber shift activation by DMX
Luminous flux(24°) 151 lm - (82°) 732lm @full
Lux(24°) 27 lx - (82°) 18lx @5 m full
Levensverwachting lichtbron> 50.000 h
CRI81 @ 6000K
R991 @ 6000K
TLCI80 @ 6000K
TM30 Rf80 @ 6000K
TM30 Rg104 @ 6000K
Optiek
Lens diameter3,93'' - 100mm
Lens typeFresnel zoom lens
Extra optieken20° filter on board
Min. Zoombereik24
Max. Zoombereik82
BedieningHandmatig
Kleuren
Manual colour modemanual adjustment of colour
KleurmengingRGBL
Wit macro's2.800 K - 8.000K
Kleurenwielvirtual colour wheel with macros
Effecten
Macrosseveral pre-build macros with adjustable speed
Behuizing
Kleur behuizingZwart, black
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM, rotatory knob
DMX kanalen1 / 2 / 3 / 4-1 / 4-2 / 5 / 9 / 6 / 7 / 9-1 / 9-2 / 12 / 14 / 17channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
RDMRDM ready for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +40°
LED Controlflicker free frequency with adjustable PWM
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik25W
Power factor>0,55
Fysieke eigenschappen
Koelingpassive cooling and fan-free
Bevestigingbracket for hanging and positioning
Signaal aansluitingDMX 5p IN/OUT
Stroomaansluiting16 A Schuko plug, Schuko
IP waarde20, IP20
Logistieke eigenschappen
Hoogte verpakking
23 cm
Breedte verpakking
34 cm
Diepte verpakking
25.5 cm
Gewicht verpakking
2.9 kg
