Lichtbron
Lichtbron500W high-power white LED
CCT(TU) 3.000 K - (DY) 5.600K
Luminous flux(DY) (15°) 26'255 lm; (45°) 32'428 lm @ full
Lux(DY) (15°) 11'975 lx - (47°) 2'306lx @5 m full
Levensverwachting lichtbron > 50.000 h
CRI(TU) >94; (DY) >91
R9(TU) >73; (DY) >80
TLCI(TU) >93; (DY) >93
TM30 Rf(TU) >92; (DY) >88
Optiek
Lens diameter250mm
Lens typeFresnel zoom lens
Zoom15° - 47° half peak angle
Kleuren
Manual colour mode manual adjust of dimmer throught menu and knob
Kleurmenging warm white
Effecten
Macros several pre-build macros with adjustable speed
Body
Pan angle(for pole operated version) 360° with manual regulation
Tilt angle(for pole operated version) 150° with manual regulation
Kleur behuizing black, white finishing available
Behuizing sturdy die-cast aluminium body
Aansturing
Protocolen DMX512, RDM, rotatory knob
DMX kanalen1 / 2 - 1 / 2 - 2 / 3 / 5channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
RDM RDM ready for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free frequency with adjustable PWM
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik500W
Output (at 230V)4 units on a single power line
Power factor>0,96
Fysieke eigenschappen
Koeling combination of heat pipe cooling system and low noise fan
Bevestiging bracket for hanging and positioning
Signaal aansluiting Amphenol XLR 5p IN/OUT connectors
Stroomaansluiting Neutrik powerCON TRUE1 IN/OUT connectors
IP waarde20
Logistieke eigenschappen
Hoogte
42.1 cm
Breedte
54.1 cm
Diepte
36.4 cm
