Lamp eigenschappen
KleursysteemMono-color
Vermogen500W
Zoom15° - 47° half peak angle
Lichtbron
Lichtbron500W high-power white LED
CCT(TU) 3.000 K - (DY) 5.600K
Luminous flux(DY) (15°) 26'255 lm; (45°) 32'428 lm @ full
Lux(DY) (15°) 11'975 lx - (47°) 2'306lx @5 m full
Levensverwachting lichtbron > 50.000 h
CRI(TU) >94; (DY) >91
R9(TU) >73; (DY) >80
TLCI(TU) >93; (DY) >93
TM30 Rf(TU) >92; (DY) >88
Optiek
Lens diameter250mm
Lens typeFresnel zoom lens
Min. Zoombereik17
Max. Zoombereik47
BedieningHandmatig
Kleuren
Manual colour mode manual adjust of dimmer throught menu and knob
Kleurmenging warm white
Effecten
Macros several pre-build macros with adjustable speed
Behuizing
Pan angle(for pole operated version) 360° with manual regulation
Tilt angle(for pole operated version) 150° with manual regulation
Kleur behuizingZwart
Materiaal sturdy die-cast aluminium body
Aansturing
Protocollen DMX512, RDM, rotatory knob
DMX kanalen1 / 2 - 1 / 2 - 2 / 3 / 5channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
RDM RDM ready for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free frequency with adjustable PWM
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik500W
Output (at 230V)4 units on a single power line
Power factor>0,96
Fysieke eigenschappen
Koeling combination of heat pipe cooling system and low noise fan
Bevestiging bracket for hanging and positioning
Signaal aansluiting Amphenol XLR 5p IN/OUT connectors
StroomaansluitingPowerCON TRUE1
IP waarde20, IP20
Logistieke eigenschappen
Hoogte verpakking
52 cm
Breedte verpakking
61.5 cm
Diepte verpakking
47.5 cm
Gewicht verpakking
20 kg
