Algemeen
Artikelnummer
21-00162
Merk
ProLights
Artikelnummer fabrikant
ECLFRESNELPDY
Garantie
2 jaar
Lamp eigenschappen
KleursysteemMono-color
Vermogen230W
Zoom17° - 42° half peak angle
Lichtbron
Lichtbron230W high-power white LED
CCT(TU) 3.200 K - (DY) 5.600K
Luminous flux(DY) (17°) 12'546 lm (42°) 15'623 lm @full
Lux(DY) (17°) 4'260 lx - (42°) 1'182lx @5 m full
Levensverwachting lichtbron> 50.000 h
CRI(TU) >98 - (DY) >95
R9(TU) >90 - (DY) >90
TLCI(TU) >98; (DY) >95
TM30 Rf(TU) >92; (DY) >89
TM30 Rg(TU) >99; (DY) >98
Optiek
Lens diameter8'' - 200mm
Lens typefresnel zoom lens
Min. Zoombereik17
Max. Zoombereik42
BedieningPole operated
Kleuren
Manual colour modemanual adjust of dimmer throught menu and knob
Kleurmengingwhite
Behuizing
Pan angle(for pole operated version) 360° with manual regulation
Tilt angle(for pole operated version) 340° with manual regulation
Kleur behuizingZwart, black, white finishing available
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM, rotatory knob
DMX kanalench1: 1 / 2 - ch2: 2 / 3 / 5channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
RDMRDM ready for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100%, manual knob dimmer
Dimmer curvesselectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free frequency with adjustable PWM
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik210W
Output (at 230V)10 units on a single power line
Power factor0,95
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingbracket for hanging and positioning
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN/OUT connectors, PowerCON TRUE1
IP waarde20, IP20
Logistieke eigenschappen
Hoogte verpakking
35 cm
Breedte verpakking
61.5 cm
Diepte verpakking
40.5 cm
Gewicht verpakking
12.3 kg
