Lichtbron
Lichtbron48x10W RGBW LEDs
CCTCCT control through dedicated DMX channel
Luminous flux(10°) 18'421 lm; (15°) 22'977 lm; (25°) 20'741 lm; (45°) 16'408 @Full
Lux(10°) 13'453 lx; (15°) 11'120 lx; (25°) 4'638 lx; (45°) 986lx @5 m full
Levensverwachting lichtbron> 50.000 hrs (L70B10 @Ta 25° C / 77° F)
Optiek
Extra optieken10° - 25° - 45° (optional) - see available accessories
Kleuren
KleurmengingRGBW / FC
Wit macro's2.800 K ~ 10.000K
Kleurenwielvirtual colour wheel with macros
Effecten
FX generatorup to 4 linear controllable sections
Macrosseveral pre-built macros with adjustable speed
Aansturing
DMX kanalen5 / 7 / 10 / 17 / 22ch
Master/Slavefor synchronised operation of more units linked in a chain
Displayuser interface through DATAMASTER external coder (not included)
Firmware upgradevia DMX with UPBOXPRO/UPBOX1 (not included)
RDMfor remote addressing and parameter configuration
Electronics
Dimmerlinear 0 - 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 ~ 30 Hz, electronic
BedrijfstemperatuurTa -20 to +45 °C (-4 to +113 °F)
Selecteerbare PWM frequentie600 to 25000 Hz (selectable steps)
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Output (at 230V)4 units on a single power line
Power factor0,95
Fysieke eigenschappen
Koelingfan-free with natural convection
Signaal aansluiting1,8 m moulded IP signal IN connector
Stroomaansluiting1,8 m moulded IP power IN/OUT connectors
IP waardeIP66 for outdoor installations
Logistieke eigenschappen
Hoogte verpakking
39.5 cm
Breedte verpakking
65 cm
Diepte verpakking
20.5 cm
Gewicht verpakking
15.5 kg
