Algemeen
Artikelnummer
21-00610
Merk
ProLights
Artikelnummer fabrikant
ARCPOD300FCLT
Garantie
2 jaar
Lichtbron
Lichtbron(6 x red, 6 x green, 6 x blue, 9 x white) 27x10W RGBW LED
CCTW: 6300K
Luminous flux(with 3° filter on-board) 10'573 lm @Full
Lux(with 3° filter on-board) 43'251lx @5 m full
Levensverwachting lichtbron> 50.000 hrs (L70B10 @Ta 25° C / 77° F)
Optiek
Lens typeTIR lenses
Extra optiekendifferent holografic filters available as options to put behind the glass - see available
Kleuren
KleurmengingRGBW
Wit macro's2.800 K ~ 10.000K
Kleurenwielvirtual colour wheel with macros
Effecten
Macrosseveral pre-built macros with adjustable speed
Behuizing
Kleur behuizingRAL 7012
Materiaalsturdy die-cast aluminium body, scratch resistant paint C5M (as standard)
Aansturing
ProtocollenDMX512, RDM
DMX kanalen5 / 7 / 10channel
Master/Slavefor synchronised operation of more units linked in a chain
Displayuser interface through DATAMASTER external coder (not included)
Firmware upgradevia DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 ~ 30 Hz, electronic
Bedrijfstemperatuur-20° C / +45° C (-4° F / +113° F) Ta
LED Controlflicker free operation
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik260W
Output (at 230V)10 units on a single power line
Power factor> 0,95
Fysieke eigenschappen
Koelingnatural convection cooling enabled by a fanless design and a chassis engineered for passiv
Signaal aansluiting1,8 m moulded IP signal IN connector
Stroomaansluiting1,8 m moulded IP power IN/OUT connectors
IP waardeIP66 for outdoor installations
Logistieke eigenschappen
Hoogte verpakking
18 cm
Breedte verpakking
66 cm
Diepte verpakking
38 cm
Gewicht verpakking
16.1 kg
