Lamp eigenschappen
KleursysteemRGBW - Full Color
AansturingDMX, RDM
Vermogen150W
SerieArcPod
Lichtbron
Lichtbron15x10W RGBW / FC LEDs
CCTCCT control through dedicated DMX channel
Luminous flux(10°) 4'552 lm; (15°) 5'678 lm; (25°) 5'732 lm; (45°) 5'390 @Full
Lux(10°) 3'116 lx; (15°) 2'790 lx; (25°) 1'203 lx; (45°) 287lx @5 m full
Levensverwachting lichtbron> 50.000 hrs (L70B10 @Ta 25° C / 77° F)
Optiek
Lens diameter36mm
Extra optieken10° - 15° - 45° (optional) - see available accessories
Kleuren
KleurmengingRGBW / FC
Wit macro's2.800 K ~ 10.000K
Kleurenwielvirtual colour wheel with presets
Effecten
Macrosseveral pre-built macros with adjustable speed
Behuizing
Kleur behuizingGrijs
MateriaalAluminium
Aansturing
ProtocollenDMX512, RDM
DMX kanalen5 / 7 / 10channel
Master/Slavefor synchronised operation of more units linked in a chain
Displayuser interface through DATAMASTER external coder (not included)
Firmware upgradevia DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Strobe / shutter1 ~ 30 Hz, electronic
Bedrijfstemperatuur-20° C / +45° C (-4° F / +113° F) Ta
LED Controlflicker free frequency with adjustable PWM
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Voedingstype230V AC
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik155W
Output (at 230V)11 units on a single power line
Power factor>0,97
Fysieke eigenschappen
Koelingfan-free projector with a chassis designed for natural convection cooling
Signaal aansluiting1,8 m moulded IP signal IN/OUT connectors
Stroomaansluiting1,8 m moulded IP power IN/OUT connectors
IP waardeIP66
Logistieke eigenschappen
Hoogte verpakking
23.5 cm
Breedte verpakking
38 cm
Diepte verpakking
34 cm
Gewicht verpakking
7 kg
