Algemeen
Artikelnummer
21-00627
Merk
ProLights
Artikelnummer fabrikant
SUNRISE4FLXFC
Garantie
2 jaar
Lichtbron
Lichtbron4 x 300W RGBWW + Amber LED
CCT CCT control, + / - green correction, tungsten emulation
Luminous flux59'378 @Full
Lux2'469lx @5 m full
Levensverwachting lichtbron > 50.000 hrs (L70B10 @Ta 25° C / 77° F)
CRI94,4 @ 3200K; 92,3 @ 5600K
R996,3 @ 3200K; 96,2 @ 5600K
Kleuren
Kleurmenging RGBA + Warm White
Wit macro's2.700 K ~ 10.000K
Behuizing
Kleur behuizing black
Materiaal Weatherproof IP65 construction with die-cast magnesium alloy
Aansturing
Protocollen DMX512, RDM, ArtNet, sACN, CRMX (optional)
DMX kanalenseveral DMX modes from 1 ch to 56channel
Display Graphic User Interface
Firmware upgrade via DMX with UPBOXPRO (USB-DMX interface not included) or via Ethernet (Art-Net with DMX-Workshop)
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves6 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -20° C / +45° C (-4° F / +113° F) Ta
LED Control flicker free frequency with adjustable PWM
Selecteerbare PWM frequentie 1000 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik1'260W
Output (at 230V)2 units on a single power line
Power factor> 0,94
Fysieke eigenschappen
Koeling active, silent operation
Bevestiging hanging bracket for floor stand. Also can fit the fast quick lock OMEGA bracket
Signaal aansluiting Seetronic XLR 5p IN/OUT connectors
Stroomaansluiting Seetronic powerCON waterproof IN connector
IP waarde IP65 for temporary outdoor application, not for fixed installations
Overige eigenschappen
Data aansluitingSeetronic IP65 Art-Net RJ45 IN/OUT
