Lamp eigenschappen
KleursysteemRGB+WW - Full Color
Vermogen200W
Lichtbron
Luminous flux3'871 lm (beam layer) | 3'114 lm (pixel layer) @Full
Lux(beam layer) 14'519 lx | (pixel layer) 46lx @5 m full
Levensverwachting lichtbron> 30.000 h
CRI(beam layer) > 81,6 @2700K; (pixel layer) 92,2 @3200K; 90 @5600K
R9(pixel layer) 94,4 @3200K; 95,4 @5600K
Optiek
Extra optiekenavailable optional optics for beam LEDs 12°, 24°
Kleuren
Kleurmenging(beam layer) Warm White (2700K), (pixel layer) RGB + Warm White
Effecten
FX generatoradjustable foreground/background colour, index, speed, direction
Macrosseveral pre-built pixel macros with adjustable speed
Control Resolution16-bit dimmer, colours
EffectenLed ring
Behuizing
Kleur behuizingZwart
Aansturing
ProtocollenDMX512, RDM, ArtNet, RDMnet, sACN, CRMX (optional)
DMX kanalenfrom 12 channels to 518channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradevia DMX with UPBOXPRO (USB-DMX interface not included) or via Ethernet (Art-Net with DMX-W
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curvesup to 6 independent selectable dimmer curves per source
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-20° C / +45° C (-4° F / +113° F) Ta
LED Controlflicker free frequency with adjustable PWM
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik170W
Output (at 230V)14 units on a single power line
Power factor> 0,94
Fysieke eigenschappen
Koelingnatural convection cooling enabled by a fanless design and a chassis engineered for passiv
Bevestigingspigot for tripod use, bracket for truss rigging and hardware for connection of more units
Signaal aansluitingIP65 Seetronic XLR 5p IN/OUT connectors
StroomaansluitingPowerCon TRUE1
IP waardeIP65
Gewicht8kg kg
Overige eigenschappen
Lichtbron1 x 14 4° 2700K LEDs + 3 x 42 120° RGB+WW LEDs
Singlecolor LED
Logistieke eigenschappen
Hoogte verpakking
17.5 cm
Breedte verpakking
113.5 cm
Diepte verpakking
26.5 cm
Gewicht verpakking
11.4 kg
