Lichtbron
Lichtbron1.024x1W RGBW LEDs
CCTW: 6.500K
Luminous fluxStrobe without lens (peak) 126000 lm; Static ON without lens 28834; Strobe with lens (peak) 46200; Static ON with lens 27188lm
Lux(120°) 410,1 lx - (40°) 1'495lx @5 m full
Levensverwachting lichtbron > 30.000 h
Kleuren
Manual colour mode manual adjustment of colour
Kleurmenging RGBW / FC
Wit macro's2.800 K -10.000K
Kleurenwiel virtual colour wheel with macros
Effecten
FX generator adjustable foreground/background colour, index, speed, direction
Roterende gobo's dynamic patterns with speed and rotation control
Behuizing
Kleur behuizing black
Materiaal sturdy die-cast aluminium body
Aansturing
Protocollen DMX512, RDM, Art-Net, Kling-Net
DMX kanalenfrom 4 ch to 87channel
Display black TFT touch display
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
RDM RDM ready for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruikstrobe: 987 W - static: 600W
Output (at 230V)3 units on a single power line
Fysieke eigenschappen
Koeling active, silent operation
Bevestiging hanging bracket for floor positioning with "Quick-Lock" system
Signaal aansluiting Amphenol XLR 5p IN/OUT connectors
Stroomaansluiting Seetronic powerCON waterproof IN/OUT connectors
IP waarde20
Logistieke eigenschappen
Hoogte verpakking
34 cm
Breedte verpakking
110 cm
Diepte verpakking
17 cm
Gewicht verpakking
13 kg
