Algemeen
Artikelnummer
21-00236
Merk
ProLights
Artikelnummer fabrikant
SUNBLAST3500MAX
Garantie
2 jaar
Lichtbron
Lichtbron1.728x1,3W high-power white LED
CCTfull ON: 6.300K
Luminous fluxstrobe: 230'000 lm - static ON: 50'638lm
Luxstrobe: 6'335 lx - static ON: 3'200lx @3 m
Levensverwachting lichtbron> 30.000 h
CRI85
Kleuren
Manual colour modemanual adjustment of dimmer and strobe
Effecten
FX generatoradjustable foreground/background colour, index, speed, direction
Roterende gobo'sdynamic patterns with speed and rotation control
Behuizing
Kleur behuizingblack
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM, Art-Net, Kling-Net
Displayblack TFT touch display
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
RDMRDM ready for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruikstrobe: 1.850 W (peak) - static: 633W
Output (at 230V)2 units on a single power line
Fysieke eigenschappen
Koelingactive, silent operation
Bevestiginghanging bracket for floor positioning with "Quick-Lock" system
Signaal aansluitingSeetronic XLR 5p IN/OUT connectors
StroomaansluitingSeetronic powerCON waterproof IN/OUT connectors
IP waarde65 for temporary outdoor application, not for fixed installation
Logistieke eigenschappen
Hoogte verpakking
35 cm
Breedte verpakking
58 cm
Diepte verpakking
27.5 cm
Gewicht verpakking
14 kg
