Algemeen
Artikelnummer
21-00543
Merk
ProLights
Artikelnummer fabrikant
ECLPENDANTSFCBK
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGBWW - Full Color
AansturingDALI, DMX, RDM
Vermogen50W
SerieEclPendant
Lichtbron
Lichtbron50W RGBWW LEDs
CCT CCT control, + / - green correction, tungsten emulation
Luminous flux2'637 @full
Lux513lx @5 m full
Levensverwachting lichtbron > 50.000 hrs (L70B10 @Ta 25° C / 77° F)
CRI92,3 @Full; 93,2 @3200K; 92,8 @5600K
R997,1 @Full; 96,2 @3200K; 92,5 @5600K
TLCI91 @Full; 80 @3200K; 89 @5600K
Optiek
Lens diameter100mm
Lens type fresnel lens
Kleuren
Kleurmenging RGB + Warm White
Kleurenwiel gel filters included
Effecten
Macros several pre-built macros with adjustable speed
Behuizing
Kleur behuizing RAL 9004 or RAL 9010
MateriaalAluminium
Aansturing
ProtocollenDALI Type8, DMX512, RDM
DMX kanalenUNO / DUO / Basic / Standard / Extendedchannel
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOXPRO/UPBOX1) not included
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1-30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free frequency with adjustable PWM
Selecteerbare PWM frequentie 600 ~ 40.000 Hz
Elektrische eigenschappen
Voedingstype230V AC
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik60W
Output (at 230V)21 units on a single power line
Power factor> 0,93
DC spanningDC 48V for emergency light use
Fysieke eigenschappen
KoelingHeatsink with heat pipes, passive cooling and fan-free
Bevestiging bracket for hanging and positioning (bracket not included on the product)
Signaal aansluitingScrew terminal block
StroomaansluitingScrew terminal block
IP waardeIP20
Montage mogelijkhedenInbouw, Opbouw, Pendel, Plafond, Wand
