Lamp eigenschappen
Zoom2.7° - 40° motorised linear zoom
Lichtbron
Lichtbron420W USHIO NSL421
CCTon wheel 2.500 K and 3.200 K + CTB
Luminous flux35.815lm
Lux(2.7°) 99.284 lx - (40°) 281lx @15 m
Levensverwachting lichtbron6.000 h
Optiek
Lens diameter153mm
Lens typeHD anti-reflection lenses with achromatic coating
Focusmotorised
Kleuren
KleurmengingCMY colour system on 3 gradually fading colour wheels
Kleurenwiel15 dichroic filters on 3 independent colour wheels
Effecten
FX generator2 prisms overlap for spectacular aerial effects
Roterende gobo's9 rotating gobos + open, interchangeable, indexing
Vaste gobo's18 fixed gobos + open
Prisma8f and 4f with bi-directional rotation, indexing
Frostlinear 0 - 100% frost filter
Gobo maatouter: 15,9 mm - image: 12 mm - thickness: 1,1 mm
Animatiewielanimation wheel with CW and CCW rotation
Behuizing
Pan angle540°
Tilt angle270°
Kleur behuizingRAL 9004
Pan/Tilt resolutiebit 8 / 16-bit
Materiaalweatherproof IP65 construction
Aansturing
ProtocollenDMX512, RDM, Art-Net, sACN, W-DMX
DMX kanalen30channel
DisplayLCD high resolution colour display with autoflip
Firmware upgradevia menu with internal memory or via USB - DMX interface (UPBOX2) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% mechanical dimmer
Strobe / shutter1 - 28 flash(s), mechanical
Bedrijfstemperatuur-20° ~ +45°
Display accuself-charging battery backup
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik590W
Output (at 230V)4 units on a single power line
Power factor> 0,96
Fysieke eigenschappen
Koelingforced air with fan
Bevestigingany position with quick-lock omega brackets
Pan / tilt lockfor transportation and maintenance
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingSeetronic powerCON TRUE IP65 IN
IP waarde65 for temporary outdoor use (*)
