Lamp eigenschappen
Zoom7°- 49° motorised linear zoom
Aansturing
Stand AloneStand Alone programmer and playback
Lichtbron
Lichtbron300W high-power white LED
CCT8.000K
Luminous flux(7°) 8'536 lm - (49°) 11'729lm @full
Lux(7°) 28'230 lx - (49°) 867lx @5 m full
Levensverwachting lichtbron> 20.000 h
Optiek
Lens diameter110mm
Lens typeHD anti-reflection lenses with achromatic coating
Focusmotorised
Kleuren
Kleurmengingcold white LED with colour wheel
Kleurenwielopen + 7 colour filters
Effecten
FX generatorshutter macros with adjustable speed
Roterende gobo'sopen + 7 rotating gobos + open, interchangeable, indexing
Prisma3ff with bi-directional rotation, indexing
Frostlinear 0 - 100% frost filter
Messen systeem4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete fr
Animatiewielmagnetic interchangeable animation wheel with CW and CCW rotation
Control Resolution16-bit dimmer
Behuizing
Kleur behuizingRAL 9006
Materiaalweatherproof IP66 construction
Aansturing
ProtocollenDMX512, RDM, W-DMX
DMX kanalen22 / 32 / 43channel
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1~30 Hz, electronic
Bedrijfstemperatuur-20° C / +45° C (-4° F / +113° F)
LED Controlflicker free frequency with adjustable PWM
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik440W
Output (at 230V)4 units on a single power line
Power factor> 0,98
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingbracket for hanging and positioning
Signaal aansluitingmoulded IP signal IN/OUT connectors
Stroomaansluitingmoulded IP power IN/OUT connectors
Logistieke eigenschappen
Hoogte verpakking
36.5 cm
Breedte verpakking
62 cm
Diepte verpakking
41.5 cm
Gewicht verpakking
23 kg
