Archwork ARCPOD36FC
Archwork ARCPOD36FC
Archwork ARCPOD36FC
Archwork ARCPOD36FC

Archwork ARCPOD36FC

22-00030

  • LED wash projector
  • 36x8 W RGBW / FC
  • IP 66

Omschrijving:

ARCPOD36 is a wash light with a 36x8 W RGBW / FC LEDs source designed for outdoor installations where a high performing projector with reliable brightness and chromatic precision is required. The rectangular shape design and the super-slim profile allow the ARCPOD36 to be easily integrated into any architectonic context whilst also integrate with outdoor (IP66) projects and installations due to the construction of chassis in die-cast aluminium and tempered glass with no fans for ventilation. ARCPOD36 is a compact projector capable of lighting large spaces, both as a stage wash in outdoor events and for architectural lighting projects

Merk

Product niet meer leverbaar

  • accessoires (5)
  • productspecificaties
  • gerelateerde producten

Accessoires

bekijk alle accessoires

Prolights ARCLUMI L15D42

21-20065

Prolights ARCLUMI L15D42
  • 15° lens
  • Diameter: 42mm
snel bekijken
Bruto prijs:
€ 2,30

Prolights ARCLUMI L25D42

21-20067

Prolights ARCLUMI L25D42
  • 25° lens
  • Diameter: 42mm
snel bekijken
Bruto prijs:
€ 4,00

Prolights ARCLUMI L45D42

21-20068

Prolights ARCLUMI L45D42
  • 45° lens
  • Diameter: 42mm
snel bekijken
Bruto prijs:
€ 3,10

ProTruss C 6002 B

24-00161

ProTruss C 6002 B
  • Halfcoupler
  • SWL: 200kg, zwart
  • 48-51mm buis
snel bekijken
Bruto prijs:
€ 11,40

ProTruss RSR 0630 B

24-00246

ProTruss RSR 0630 B
  • Safety kabel, lengte 60cm
  • 3mm, maximaal 25kg
  • Kleur: zwart
snel bekijken
Bruto prijs:
€ 4,80
bekijk alle accessoires

Gegevens

Algemeen

Artikelnummer 22-00030
Merk ArchWork
Artikelnummer fabrikant ARCPOD36FC
Garantie 2 jaar

Lichtbron

Lichtbron36x8W RGBW / FC LEDs
Luminous flux@full 7'769lm
Lux15° @full 3'395lx @5 m
Levensverwachting lichtbron 50.000 hrs (L70 @25° C / 77° F)

Optiek

Extra optieken25° / 45° (optional)

Kleuren

Manual colour mode manual adjustment of colour
Kleurmenging RGBW / FC
Wit macro's3.200 K ~ 10.000K
Kleurenwiel virtual colour wheel with macros

Effecten

Macros several pre-build macros with adjustable speed

Behuizing

Kleur behuizing RAL 9003
Materiaal sturdy die-cast aluminium body

Aansturing

Protocollen DMX512
DMX kanalen4 / 6 / 10channel
Master/Slave for synchronised operation of more units linked in a chain
Display touch - sensitive LED display
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included

Electronics

Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -20° C / +45° C (-4° F / +113° F)
LED Control flicker free operation

Elektrische eigenschappen

Netvoeding100-240 V 50/60 Hz
Max. stroomverbruik235W
Output (at 230V)6 units on a single power line

Fysieke eigenschappen

Koeling pressure and temperature balance through GORE membrane vents
Bevestiging bracket for hanging and positioning
Signaal aansluiting moulded IP signal IN/OUT connectors
Stroomaansluiting moulded IP signal IN/OUT connectors
IP waarde66 for outdoor installations

Logistieke eigenschappen

Hoogte verpakking 33.8 cm
Breedte verpakking 57.9 cm
Diepte verpakking 11.5 cm
Gewicht verpakking 16.66 kg
