Lamp eigenschappen
KleursysteemRGBW - Full Color
Vermogen60W
Lichtbron
Lichtbron60W RGBW Osram LED
CCTlinear CTO correction 2.700 K ~ 6.000 K
Luminous flux1,069lm
Lux1,682lx @3 m full
Levensverwachting lichtbron> 50.000 h
Optiek
Lens typehigh-quality glass lens optics
Focusmotorised
Min. Zoombereik19
Kleuren
KleurmengingRGBW / FC
Kleurenwielvirtual colour wheel with macros
Effecten
Roterende gobo's7 rotating gobos + open, interchangeable
Prisma3f with bi-directional rotation
Gobo maatgobo Ø 16.9 mm - img Ø 14 mm - 0.2 mm
EffectenFocus, Prisma
Behuizing
Pan angle540°
Tilt angle270°
Kleur behuizingWit, black, white finishing available
Pan/Tilt resolutiebit 8 / 16bit
Materiaalaluminium structure with hi-resistance polycarbonate cover
Aansturing
ProtocollenDMX512
DMX kanalen15 / 18 / 23channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
W-DMXoptional, proprietary protocol compatible with WIFIBOX, WDBOX
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curvesselectable dimming modes available
Strobe / shutter1 / 28 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free operation
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik118W
Output (at 230V)17 units on a single power line
Fysieke eigenschappen
Koelingactive, silent operation
Bevestigingany position with quick-lock omega brackets
Signaal aansluitingXLR 3p IN/OUT connectors
StroomaansluitingEuro, IEC IN/OUT connectors
IP waarde20, IP20
Gewicht7 kg
Logistieke eigenschappen
Hoogte verpakking
35.2 cm
Breedte verpakking
25.3 cm
Diepte verpakking
19.2 cm
Gewicht verpakking
7 kg
