Lichtbron
Lichtbron96x3W RGBW LEDs
Luminous fluxwithout filter: 3'019,9 lm - with 50° filter: 2'117 lm - with 60 x 10° filter: 2'261lm
Luxwithout filter: 1'593 lx - with 50° filter: 404 lx - with 60 x 10° filter: 608lx @3 m full
Levensverwachting lichtbron > 50.000 h
Optiek
Extra optiekenmagnetic 60 x 10° asymmetric filter (optional)
Kleuren
Manual colour mode manual adjustment of colour
Kleurmenging RGBW
Kleurenwiel virtual colour wheel with macros
Behuizing
Tilt angle0 - 90°
Kleur behuizing black
Materiaal sturdy die-cast aluminium body
Aansturing
Protocollen W-DMX
DMX kanalen4 / 6 / 10channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
W-DMX included, wireless solution receiver
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur 0° ~ +45°
LED Control flicker free operation
Elektrische eigenschappen
Max. stroomverbruik424W
Batterij26 A h - 18,5V
Fysieke eigenschappen
Koeling passive cooling and fan-free
Stroomaansluiting quick lock magnetic fast charge connector
IP waarde65 for temporary outdoor application, not for fixed installation
Oplaad connectie magnetic fast-charge in case
Logistieke eigenschappen
Hoogte verpakking
21.3 cm
Breedte verpakking
40.6 cm
Diepte verpakking
101.5 cm
Gewicht verpakking
8.4 kg
