Lamp eigenschappen
KleursysteemRGBWW - Full Color
Vermogen150W
Lichtbron
Lichtbron150W RGB + Warm White
CCT CCT control, + / - green correction, tungsten emulation
Luminous flux(24°) 5'983 lm - (73°) 5'774lm @full
Lux(24°) 1'040 lux - (73°) 166lx @5 m full
Levensverwachting lichtbron > 50.000 h
CRI95@ 3200K; 92 @ 5600K
R998 @ 3200K; 96 @ 5600K
TLCI85 @ 5600K
TM30 Rf92 @ 3200K; 90 @ 5600K
TM30 Rg105 @ 3200K; 106 @ 5600K
Optiek
Lens diameter163mm
Lens type fresnel lens
Extra optieken24° lens on board - 73° lens included - 40° lens optional - egg crate optional - barndoors optional - gel frame holder included
Min. Zoombereik24
Kleuren
Manual colour mode manual adjustment of colour
Kleurmenging RGB + Warm White
Wit macro's2.800 K - 6.500K
Kleurenwiel virtual colour wheel with macros
Effecten
Macros built-in white presets
Behuizing
Kleur behuizingZwart
Materiaal sturdy die-cast aluminium body
Aansturing
Protocollen DMX512, RDM
DMX kanalen(theatre) 1 / 2 / 4 / 5 / 6 / 10 / 15 / 17 ch - (tour) 4 / 6 / 10 / 15channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
RDM RDM ready for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free operation
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik150W
Output (at 230V)14 units on a single power line
Power factor> 0.92
Fysieke eigenschappen
Koeling active, silent operation
Bevestiging any position with quick-lock omega brackets
Signaal aansluiting Amphenol XLR 3p + 5p IN/OUT connectors
StroomaansluitingPowerCon
IP waarde20, IP20
Logistieke eigenschappen
Hoogte verpakking
31.6 cm
Breedte verpakking
45 cm
Diepte verpakking
20.8 cm
