Lichtbron
Lichtbron230W high-power white LED
CCT(TU) 3.200 K - (DY) 5.700K
Luminous flux(DY) 5°: TBD - 10°: TBD - 14°: 9'649 lm -19°: 9'822 lm - 26°: 10'974 lm - 3
Lux(DY) 5°: TBD - 10°: TBD - 14°: 12'000 lx - 19°: 7'118 lx - 26°: 5'571 lx -
Levensverwachting lichtbron> 50.000 h
CRI(TU) >97; (DY) >96
R9(TU) >87; (DY) >96
TLCI(TU) >97; (DY) >96
TM30 Rf(TU) >92; (DY) >89
TM30 Rg(TU) 100; (DY) 100
Optiek
Lens typehigh-quality glass lens optics
Focusmanual
Kleuren
Manual colour modemanual adjustment of colour
Kleurmengingstatic white
Effecten
Gobo maatB, outer: 86 mm - image: 64,5 mm - thickness: 1,1 mm
Behuizing
Kleur behuizingblack
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM
DMX kanalen1 / 2 / 5channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
RDMRDM ready for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free operation
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik230W
Output (at 230V)15 units on a single power line
Power factorTU: >0.90 - DY: >0,94
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingbracket for hanging and positioning
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON IN/OUT connectors
IP waarde20
Logistieke eigenschappen
Hoogte verpakking
34.2 cm
Breedte verpakking
52.8 cm
Diepte verpakking
52.6 cm
Gewicht verpakking
7.11 kg
