Lamp eigenschappen
KleursysteemMono-color
AansturingDMX, RDM, W-DMX G3
Vermogen540W
Zoom6,6° - 50° motorised linear zoom
SerieMosaico
Lichtbron
Lichtbron540W high-power white LED
CCT linear CTO correction 3.000 K ~ 6.000 K
Luminous flux(6,6°) 8'812 lm - (50°) 14'253lm
Lux(6,6°) 33'138 lx - (50°) 1'138lx @5 m full
Levensverwachting lichtbron 30.000 hrs (L70 @25° C / 77° F)
Optiek
Lens diameter119mm
Lens type high-quality glass lens optics
Focus motorised
Kleuren
Kleurmenging linear CMY
Kleurenwiel6 colour filters
Effecten
Roterende gobo's7 rotating gobos + open, interchangeable, indexing
Prisma4f with bi-directional rotation, indexing
Frost dual frost filter, soft-edge and heavy
Gobo maatgobo Ø 26,9 mm - img Ø 20,5 mm - 1,1 mm
Messen systeem 4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete framing system
Animatiewiel animation wheel with CW and CCW rotation
Iris5 ~ 100% motorised iris
Behuizing
Kleur behuizing RAL 9006
MateriaalAluminium
Aansturing
Protocollen DMX512, RDM, W-DMX, Stand Alone programmer and playback
DMX kanalen28 / 30 / 35 / 44channel
Master/Slave for synchronised operation of more units linked in a chain
Display black OLED touch display
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
W-DMX included, wireless solution receiver
RDM RDM ready for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -20° C / +45° C (-4° F / +113° F)
LED Control flicker free operation
Display accu self-charging battery backup
Elektrische eigenschappen
Voedingstype230V AC
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik600W
Power factor>0,96
Fysieke eigenschappen
Koeling active, with IP low noise fan
Bevestiging bracket for hanging and positioning
Signaal aansluiting moulded IP signal IN/OUT connectors
Stroomaansluiting moulded IP power IN/OUT connectors
IP waarde66 for outdoor installations, IP66
Montage mogelijkhedenOpbouw
Logistieke eigenschappen
Hoogte verpakking
40.1 cm
Breedte verpakking
60.9 cm
Diepte verpakking
30 cm
