Algemeen
Artikelnummer
21-00116
Merk
ProLights
Artikelnummer fabrikant
STUDIOCOBPLUSUV
Garantie
2 jaar
Lichtbron
Lichtbron457nm 108W COB UV LED
Luminous flux(18°) without filter: 137,21lm - (18°) with filter: 128,92 lm - (38°) without filter: 129,07 lm - (38°) with filter: 120,63lm
Lux(18°) 7'481 lx - (38°) 1'830lx @5 m with filter
Levensverwachting lichtbron > 50.000 h
CRI55,4
R95
Optiek
Lens diameter149,5mm
Lens type UV PMMA lens
Extra optieken18° lens on board and 38° lens in the package
Kleuren
Manual colour mode manual adjustment of dimmer and strobe
Kleurenwiel virtual colour wheel with macros
Behuizing
Tilt angle° with 360° continuous rotation
Kleur behuizing black
Materiaal aluminium body
Aansturing
Protocollen DMX512, RDM
DMX kanalen1 / 2 / 5channel
Master/Slave for synchronised operation of more units linked in a chain
Display black OLED touch display
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
RDM RDM ready for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Strobe / shutter1 - 28 Hz, electronic
Bedrijfstemperatuur -20° ~ +45°
LED Control flicker free frequency with adjustable PWM
Display accu self-charging battery backup
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik132W
Output (at 230V)13 units on a single power line
Power factor0,98 (120V) - 0,90 (230V)
Fysieke eigenschappen
Koelinglow noise fan pressure and temperature balance through GORE membrane vents
Bevestiginghanging bracket suitable for safe hanging and positioning
Signaal aansluiting 5p IP IN/OUT
Stroomaansluiting IP IN/OUT power connector
IP waarde65 for temporary outdoor application, not for fixed installation
Logistieke eigenschappen
Hoogte verpakking
18.7 cm
Breedte verpakking
25.9 cm
Diepte verpakking
37 cm
