Lichtbron
Lichtbron12x8W RGBW LED
Luminous flux3'550lm
Lux(15°) 2'902lx @3 m full
Levensverwachting lichtbron > 50.000 h
Optiek
Lens diameter42mm
Extra optieken25° - 45° (optional)
Kleuren
Manual colour mode manual adjustment of colour
Kleurmenging RGBW / FC
Kleurenwiel virtual colour wheel with macros
Effecten
Macros several pre-build pixel macros with adjustable speed
Behuizing
Kleur behuizing black
Materiaal sturdy die-cast aluminium body
Aansturing
Protocollen DMX512
DMX kanalen4 / 6 / 10 / 48 / 53channel
Master/Slave for synchronised operation of more units linked in a chain
Display LCD display
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves5 selectable dimming modes available
Strobe / shutter1 - 25 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free operation
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik120W
Output (at 230V)16 units on a single power line
Fysieke eigenschappen
Koeling passive cooling and fan-free
Bevestiging bracket for hanging and positioning
Signaal aansluiting IP IN/OUT DMX connector
Stroomaansluiting IP IN/OUT power connector
IP waarde65 with a protective vent to prevent condensation, dust, compensate pressure
Logistieke eigenschappen
Hoogte verpakking
10 cm
Breedte verpakking
99.5 cm
Diepte verpakking
18.6 cm
Gewicht verpakking
7 kg
