Algemeen
Artikelnummer
21-00025
Merk
ProLights
Artikelnummer fabrikant
ARIA700PROFILE
Garantie
2 jaar
Lamp eigenschappen
Zoom10,8° - 45,7° motorised linear zoom
Lichtbron
Lichtbron400W custom RGBW LED
CCTCCT control through dedicated DMX channel
Luminous flux(10,8°) 5'363 lm - (45,7°) 5'468lm @full
Lux(10,8°) 8'460 lx - (45,7°) 688lx @5 m full
Levensverwachting lichtbron50.000 h
Optiek
Lens typeHD anti-reflection lenses with achromatic coating
Focusmotorised with auto-focus
Kleuren
KleurmengingRGBW / FC
Wit macro's2000 K ~ 8000K
Kleurenwielvirtual colour wheel with macros
Effecten
FX generatorshutter macros with adjustable speed
Roterende gobo's7 rotating gobos + open, interchangeable, indexing
Prisma3f with bi-directional rotation, indexing
Frostlinear 0 - 100% frost filter
Gobo maatouter: 26,7 mm - image: 22 mm - thickness: 0,3 mm
Messen systeem4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete fr
Animatiewielanimation wheel with CW and CCW rotation
Iris5 - 100% motorised iris
Behuizing
Pan angle540°
Tilt angle250°
Kleur behuizingblack
Pan/Tilt resolutiebit 16bit
Materiaalaluminium structure with hi-resistance polycarbonate cover
Aansturing
ProtocollenDMX512, RDM, Art-Net, W-DMX
DMX kanalen33 / 38 / 39channel
DisplayLCD high resolution colour display with autoflip
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
W-DMXincluded, wireless solution receiver
RDMRDM ready for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 28 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free operation
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik390W
Output (at 230V)8 units on a single power line
Power factor> 0,94
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingany position with quick-lock omega brackets
Pan / tilt lockfor transportation and maintenance
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN/OUT connectors
IP waarde20
Logistieke eigenschappen
Hoogte verpakking
52.6 cm
Breedte verpakking
40.8 cm
Diepte verpakking
47.4 cm
Gewicht verpakking
27 kg
