Lamp eigenschappen
KleursysteemRGBW - Full Color
Vermogen310W
Zoom3° - 45° motorised linear zoom
Lichtbron
Lichtbron8x40W RGBW Osram Ostar LEDs
CCTTunable 2.000 K ~ 10.000K
Lux(3°) 36'391 lx - (45°) 3'113lx @3 m full
Levensverwachting lichtbron> 50.000 h
Optiek
Lens diametersquare 50x50mm
Lens typehigh-quality glass lens optics
Min. Zoombereik3
Max. Zoombereik45
Kleuren
Manual colour modemanual adjustment of colour
KleurmengingRGBW / FC
Wit macro's2.000 K ~ 10.000K
Kleurenwielvirtual colour wheel with macros
Effecten
FX generatoradjustable foreground/background colour, index, speed, direction
Macrosseveral pre-build pixel macros with adjustable speed
EffectenLed ring
Behuizing
Pan angle540° / 630° with 360° continuous rotation
Tilt angle360° with 360° continuous rotation
Kleur behuizingZwart, black
Pan/Tilt resolutiebit 16bit
Materiaalaluminium structure with hi-resistance polycarbonate cover
Aansturing
ProtocollenDMX512, RDM, Art-Net, W-DMX
DMX kanalen17 / 27 / 55channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayLCD high resolution colour display with autoflip
Firmware upgradevia menu with internal memory or via USB - DMX interface (UPBOX2) not included
W-DMXincluded, wireless solution receiver
RDMRDM ready for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curvesselectable dimming modes available
Strobe / shutter1 - 25 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free operation
Slaapstandpower safe mode when lost DMX
Display accuself-charging battery backup
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik310W
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingany position with quick-lock omega brackets
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN connector, PowerCON TRUE1
IP waarde20, IP20
Gewicht12 kg
Logistieke eigenschappen
Hoogte verpakking
43.3 cm
Breedte verpakking
56 cm
Diepte verpakking
20 cm
Gewicht verpakking
12 kg
