Lamp eigenschappen
Zoom3° - 45° motorised linear zoom
Lichtbron
Lichtbron18x40W RGBW Osram Ostar LEDs
CCTCCT control through dedicated DMX channel
Lux(3°) 42'530 lx - (45°) 6'782lx @3 m full
Levensverwachting lichtbron> 50.000 h
Optiek
Lens diametersquare 50x50mm
Lens typehigh-quality glass lens optics
Kleuren
Manual colour modemanual adjustment of colour
KleurmengingRGBW / FC
Wit macro's2.000 K ~ 10.000K
Kleurenwielvirtual colour wheel with macros
Effecten
FX generatoradjustable foreground/background colour, index, speed, direction
Macrosseveral pre-build pixel macros with adjustable speed
Behuizing
Tilt angle265°
Kleur behuizingblack
Pan/Tilt resolutiebit 16bit
Materiaalaluminium structure with hi-resistance polycarbonate cover
Aansturing
ProtocollenDMX512, RDM, Art-Net, W-DMX
DMX kanalen13 / 23 / 91channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayLCD high resolution colour display with autoflip
Firmware upgradeyes, via USB - DMX interface (UPBOX2) not included
W-DMXincluded, wireless solution receiver
RDMRDM ready for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curvesselectable dimming modes available
Strobe / shutter1 - 25 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free operation
Slaapstandpower safe mode when lost DMX
Display accuself-charging battery backup
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik583W
Output (at 230V)6 units on a single power line
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestiginghanging bracket for floor positioning with "Quick-Lock" system
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN/OUT connectors
IP waarde20
Logistieke eigenschappen
Hoogte verpakking
34 cm
Breedte verpakking
100 cm
Diepte verpakking
21 cm
Gewicht verpakking
19 kg
