Lamp eigenschappen
Zoom7° - 40° motorised linear zoom
Lichtbron
Lichtbron60W RGBW Osram Ostar LED
CCTCCT control through dedicated DMX channel
Luminous flux(7°) 1'432 lm - (40°) 1'311lm @full
Lux(7°) 3'808 lx - (40°) 296lx @5 m full
Levensverwachting lichtbron> 50.000 h
Optiek
Lens diameter100mm
Lens typehigh-quality glass lens optics
Kleuren
KleurmengingRGBW / FC
Wit macro's2.700 K ~ 8.000K
Kleurenwielvirtual colour wheel with macros
Behuizing
Pan angle540°
Tilt angle270°
Kleur behuizingblack, white finishing available
Pan/Tilt resolutiebit 8 / 16bit
Materiaalaluminium structure with hi-resistance polycarbonate cover
Aansturing
ProtocollenDMX512
DMX kanalen13 / 16channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free operation
Display accuself-charging battery backup
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik100W
Output (at 230V)22 units on a single power line
Fysieke eigenschappen
Koelingactive, silent operation
Bevestigingany position with quick-lock omega brackets
Signaal aansluitingXLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON IN/OUT connectors
IP waarde20
Logistieke eigenschappen
Hoogte verpakking
32 cm
Breedte verpakking
25.2 cm
Diepte verpakking
20.4 cm
Gewicht verpakking
7 kg
