Lamp eigenschappen
Zoom5° - 50° motorised linear zoom
Lichtbron
Lichtbron440W high-power white LED
CCTlinear CTO correction 2.700 K ~ 6.000 K
Lux(5°) 26'533 lx - (50°) 1'535lx @5 m full
Levensverwachting lichtbron> 20.000 h
Optiek
Lens diameter120mm
Lens typeHD anti-reflection lenses with achromatic coating
Focusmotorised with auto-focus
Kleuren
Kleurmenginglinear CMY
Kleurenwiel7 colour filters
Effecten
Roterende gobo's6 rotating gobos + open, interchangeable, indexing
Vaste gobo's7 fixed gobos + open, interchangeable
Prisma3f with bi-directional rotation, indexing
Frostlinear 0 - 100% frost filter
Gobo maatouter: 26,7 mm - image: 20 mm - thickness: 1,1 mm
Messen systeem(inc) 4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the compl
Animatiewiel(opt) animation wheel with CW and CCW rotation
Iris5 - 100% motorised iris
Behuizing
Pan angle630° - 540°
Tilt angle267°
Kleur behuizingblack
Pan/Tilt resolutiebit 8 / 16bit
Materiaalaluminium structure with hi-resistance polycarbonate cover
Aansturing
ProtocollenDMX512, RDM, W-DMX
DMX kanalen28 / 30 / 37 / 38channel
DisplayLCD high resolution colour display
Firmware upgradeyes, via USB - DMX interface (UPBOX2) not included
W-DMXincluded, wireless solution receiver
RDMRDM ready for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Strobe / shutter1 - 28 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
Slaapstandpower safe mode when lost DMX
Display accuself-charging battery backup
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik650W
Power factor0,98
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingany position with quick-lock omega brackets
Pan / tilt lockfor transportation and maintenance
Signaal aansluitingAmphenol XLR 3p + 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN connector
IP waarde20
Logistieke eigenschappen
Hoogte verpakking
75.8 cm
Breedte verpakking
42.8 cm
Diepte verpakking
28.5 cm
Gewicht verpakking
30 kg
